Operation Counters and Energy Estimation#

This tutorial covers spikingjelly.activation_based.op_counter. It counts FLOPs, memory accesses, SynOps, MACs, and ACs during one execution, then uses those counts to estimate energy. Results depend on input shape, spike sparsity, and train/eval mode, so profile a configuration that represents the target workload.

Overview#

Runtime Counting Modes#

op_counter observes runtime calls through three context managers:

DispatchCounterMode intercepts ATen operators;
FunctionCounterMode intercepts torch.* functions;
ModuleCounterMode records executed nn.Module forward and backward events.

The modes are active only inside their contexts and do not modify the model. Multiple counters can observe the same execution. Unlike static shape analysis, runtime counting distinguishes binary spikes from dense activations and reflects changes in input sparsity and execution stage.

Basic Counting Workflow#

Using `DispatchCounterMode`#

instantiate one or more counters;
run one real forward or forward-backward pass inside DispatchCounterMode;
read per-scope counts from get_counts() or the global total from get_total().

Both train() and eval() can be counted. For modules such as dropout or batch normalization, use the mode that matches the target workload.

import torch
import torch.nn as nn
from spikingjelly.activation_based import neuron, op_counter

model = nn.Sequential(
    nn.Linear(8, 16, bias=False),
    neuron.IFNode(),
    nn.Linear(16, 4, bias=False),
)
x = (torch.rand(2, 8) > 0.5).float()

flop_counter = op_counter.FlopCounter()
mem_counter = op_counter.MemoryAccessCounter()

with op_counter.DispatchCounterMode(
    [flop_counter, mem_counter],
    strict=False,
):
    _ = model(x)

print("FLOPs:", flop_counter.get_total())
print("Memory access (bytes):", mem_counter.get_total())
print("Global FLOP record:", flop_counter.get_counts()["Global"])

The package logger emits per-operation DEBUG records. They can be expensive on large models, so enable them only while diagnosing counts:

from spikingjelly.logger import logger

logger.enable("spikingjelly")

The dispatch examples use strict=False and skip unsupported auxiliary operators. After confirming coverage, use strict=True to fail on unsupported operators.

Using `ModuleCounterMode`#

Module-counter rule keys are ("forward" | "backward", module_type). ModuleCounterMode manages hooks, scopes, and exception cleanup, but does not reset counters. Scopes start with Global, followed by the root module type and qualified child paths.

memory_counter = op_counter.NeuromorphicMemoryAccessCounter()
with op_counter.ModuleCounterMode(
    [memory_counter], model=model, strict=True
):
    _ = model(x)

print(memory_counter.get_counts()["Global"])

After any mode exits, call mode.get_unsupported(counter) to inspect subjects skipped by a non-strict run.

Available Counters#

FlopCounter: counts floating-point operations. It is useful for ANN-style compute intensity analysis.
MemoryAccessCounter: counts runtime memory traffic in bytes.
SynOpCounter: counts spike-driven synaptic additions. Dense floating-point inputs do not contribute to SynOps.
MACCounter: counts multiply-accumulate operations.
ACCounter: counts addition-like arithmetic work that is not modeled as MAC.

The counters measure different work. A spike-driven linear layer may produce SynOps and ACs but no MACs. SynOpCounter counts only binary spike inputs; dense floating-point inputs produce zero SynOps.

import torch
import torch.nn as nn
from spikingjelly.activation_based import op_counter

model = nn.Linear(8, 4, bias=False)
spike_x = (torch.rand(2, 8) > 0.5).float()

synop_counter = op_counter.SynOpCounter()
with op_counter.DispatchCounterMode([synop_counter], strict=False):
    _ = model(spike_x)

print("SynOps:", synop_counter.get_total())

Roofline Analysis Example#

The following example counts FLOPs, memory access, and arithmetic intensity for one training step. Remove backward() for inference.

import torch
import torch.nn as nn
from spikingjelly.activation_based import op_counter

model = nn.Sequential(
    nn.Conv2d(2, 4, kernel_size=3, padding=1, bias=False),
    nn.Conv2d(4, 8, kernel_size=3, padding=1, bias=False),
)
x = torch.rand(1, 2, 16, 16)

flop_counter = op_counter.FlopCounter()
mem_counter = op_counter.MemoryAccessCounter()

with op_counter.DispatchCounterMode([flop_counter, mem_counter], strict=False):
    y = model(x)
    y.sum().backward()

flops = flop_counter.get_total()
mem_bytes = mem_counter.get_total()
intensity = flops / mem_bytes if mem_bytes > 0 else float("inf")

print("total FLOPs:", flops)
print("total memory access (bytes):", mem_bytes)
print("arithmetic intensity (FLOPs/byte):", intensity)

The result is the workload point for a roofline chart; combine it with hardware peak FLOPs and bandwidth. The counts use an idealized model: two FLOPs per MAC, one read per logical input, and one write per logical output. They exclude tiling, caches, fusion, bank conflicts, and physical DRAM traffic.

High-Level Energy Models#

Model Overview#

op_counter exposes four high-level entry points and five energy regimes:

estimate_simple_energy: simple runtime MAC/AC/memory energy;
estimate_lemaire_energy: Lemaire-aligned analytical forward inference energy;
estimate_neuromc_runtime_energy: runtime NeuroMC-style energy;
estimate_spikesim_energy: runtime SpikeSim dense or event Conv2d energy.

Simple Energy and SpikeSim event are defined by SpikingJelly. Lemaire follows the paper; NeuroMC and SpikeSim dense follow author models. Source-conformance evaluation covers Lemaire, NeuroMC, and SpikeSim dense. Simple Energy and SpikeSim event have no independent external reference.

Estimator	Main purpose	Covers	Main boundary
`estimate_simple_energy`	normalized runtime energy comparison	MAC, AC, weight/bias reads, and persistent neuron-state accesses	excludes signal flow, FIFOs, routing, addressing, and hardware mapping
`estimate_lemaire_energy`	forward SNN inference estimate aligned with Lemaire-style formulas	ops, addressing, runtime-sized memory traffic, neuron-state traffic	forward inference only; analytical estimate, not hardware simulation
`estimate_neuromc_runtime_energy`	runtime energy for forward, backward, and optimizer stages	compute and memory under NeuroMC-like mapping rules	covers only supported fragments and stage semantics
`estimate_spikesim_energy`	SpikeSim-style Conv2d accelerator estimate	Conv2d stage energy with SpikeSim coefficients	only for supported Conv2d inference stages; not a general full-model energy estimator

The five regimes use different costs and hardware assumptions. Do not compare their absolute values.

Every report exposes model_info with a stable model ID, sources, technology, precision, scope, and fidelity. config (memory_config for NeuroMC) records the actual cost configuration. paper and reference-code identify upstream parity, source-aligned identifies an upstream-cost runtime adapter, and spikingjelly-defined identifies a formula specified by this project. Report the estimator, execution stages, cost configuration, input type, and sparsity.

Simple Runtime Energy#

estimate_simple_energy runs one forward pass and converts runtime counts with MAC * E_MAC + AC * E_AC + bytes * E_memory.

Its main assumptions are:

NeuromorphicMemoryAccessCounter independently counts weights and biases that are actually used, plus one read and one write per timestep for persistent neuron states;
input currents and output spikes are treated as on-chip signal flow, not memory;
it does not model FIFOs, addressing, routing, cache reuse, or hardware mapping;
SynOps is an auxiliary subset of AC and is not charged a second time;
defaults use Horowitz 2014 FP32 arithmetic and STEP Table 9's 24.96 pJ/byte memory cost; SpikingJelly defines the traffic formula;
FP16 and INT8 presets change arithmetic costs but do not quantize the model.

Lemaire Analytical Inference Energy#

estimate_lemaire_energy runs one forward pass and maps synaptic operations, MAC/AC work, addressing, neuron state, and per-layer SRAM accesses to the Lemaire equations. Its main limits are:

forward inference only;
analytical estimation, not cycle-accurate hardware simulation;
operations and accesses keep the paper's fixed 32-bit regime regardless of the host tensor dtype;
parameter, FIFO, and potential accesses are priced against each layer's local SRAM capacity before energy is aggregated;
binary inputs use the SNN event formulas, while sparse non-binary inputs remain on the dense FNN path;
grouped and depthwise convolutions use output channels per group for spike fanout;
neuron modules are limited to the paper's IF/LIF scope; other BaseNode types are rejected by default;
SNN FIFOs hold 1000 messages by default; override snn_fifo_capacity_elements for another assumption;
strict=True is the default and rejects unsupported transposed convolutions; explicitly setting it to False warns and omits them.

NeuroMC Runtime Energy#

estimate_neuromc_runtime_energy profiles real execution fragments and maps them through the fixed NeuroMC weight-stationary FE/BE/WE mapping and v1 cost table. Results follow the executed branches, call counts, and tensor shapes; unexecuted modules do not enter the report.

The author code uses ZigZag to derive MAC, partial-sum, and memory traffic from static workloads and mappings. SpikingJelly does not invoke ZigZag at runtime; it applies the same fixed 16x16 weight-stationary mapping to captured fragments. Both paths use the same loop dimensions, data-movement rules, and cost constants. The runtime calculation depends on fragment shapes, not network names or layer IDs.

The convenience function always runs forward. Adding target and loss_fn runs backward; adding optimizer also estimates the optimizer stage. Use NeuroMCEnergyProfiler for manual stages.

Its main limits are:

unsupported energy-bearing operators reject totals;
manual profiling passes mapping semantics explicitly with stage(name, phase=..., reuse_weights=..., batch_norm_backward=...); a stage name reused in one context must keep the same options;
the convenience function clears existing gradients but does not call optimizer.step() or update parameters;
repeated calls to one module must all participate in backward; selective backward through only some calls is rejected as ambiguous;
results come from a hardware model, not measurements from a real chip.

SpikeSim Runtime Energy#

estimate_spikesim_energy counts executed Conv2d inference stages. The default dense mode uses the author-code PE-cycle formula; event uses a sparse formula defined by SpikingJelly. Here, dense means charging the full PE cycles for an executed convolution; it does not mean a fully connected layer, and zero-valued inputs do not reduce its energy. Its main limits are:

the model should be in eval mode; with the default strict=True, unsupported Conv2d stages and empty reports fail;
only supported Conv2d forward stages enter the main energy path;
with the default activity_mode="dense", runtime spike sparsity does not reduce energy;
activity_mode="event" selects spikingjelly_spikesim_event_v1 model using SpikeSim constants and SpikingJelly's documented A/R/Z sparse formula;
require_if_lif_neurons=True accepts only IF/LIF-style neurons.

Energy Estimation Example#

Simple Energy Example#

Run inference estimators after model.eval(). The first example uses Simple Energy:

import torch
import torch.nn as nn
from spikingjelly.activation_based import op_counter

model = nn.Linear(8, 4, bias=False).eval()
x = torch.rand(2, 8)

report = op_counter.estimate_simple_energy(model, x)

print("total energy (pJ):", report.energy_total_pj)
print("compute energy (pJ):", report.energy_compute_pj)
print("MAC energy (pJ):", report.energy_mac_pj)
print("AC energy (pJ):", report.energy_ac_pj)
print("memory energy (pJ):", report.energy_memory_pj)
print("counts:", report.counts)

Select another cost regime explicitly:

cfg = op_counter.SimpleEnergyConfig(
    cost_config=op_counter.SimpleEnergyCostConfig.fp16()
)
report_fp16 = op_counter.estimate_simple_energy(model, x, config=cfg)
print("FP16-regime energy (pJ):", report_fp16.energy_total_pj)

The Lemaire estimator also includes addressing and neuron state:

import torch
import torch.nn as nn
from spikingjelly.activation_based import neuron, op_counter

model_snn = nn.Sequential(
    nn.Linear(8, 16, bias=False),
    neuron.IFNode(),
    nn.Linear(16, 4, bias=False),
).eval()
spike_x = (torch.rand(2, 8) > 0.5).float()

lemaire_report = op_counter.estimate_lemaire_energy(model_snn, spike_x)
print("Lemaire total (pJ):", lemaire_report.total_pj)
print("Lemaire breakdown:", lemaire_report.breakdown_pj)

Validation and Sources#

Primary Sources#

Simple arithmetic costs: Horowitz 2014; memory coefficient: STEP Table 9.
Lemaire: An Analytical Estimation of Spiking Neural Networks Energy Efficiency.
SpikeSim dense: author-code commit c2627bc.
NeuroMC: author-code commit 712c66f.

Source-Model Conformance#

This benchmark checks conformance with the source models, not hardware accuracy. Each case records one (E_origin, E_SJ) pair. SpikeSim and NeuroMC use pinned author code. Lemaire has no public code, so its reference values follow equations (1)--(20).

SpikeSim and Lemaire cases come from parameter grids in the script. NeuroMC covers all FE, BE, and WE fragments from the official S-ResNet-18, S-ResNet-50, and S-VGG-16 workloads, for 786 cases in total. SpikingJelly runs the matching PyTorch forward or backward execution; author modules are reloaded before each case to avoid shared mutable state.

Lemaire did not publish source code; the paper states that code and models are available from the authors on request. For FC cases, theta_in is the observed input-spike count. Equation (2) multiplies this value by N_in again, unlike the definition and Eqs. (8), (10), (15), and (17). This benchmark counts one N_out fanout per observed input spike.

Kendall's tau-b is the primary metric, with a paired 2,000-sample 95% bootstrap interval. Spearman's rho and log-Pearson r are secondary metrics. Raw P90 measures absolute symmetric error without calibration. Scale-adjusted P90 removes the median multiplicative scale and is used only to diagnose shape error. NeuroMC FE, BE, WE, and aggregate results must all satisfy tau-b >= 0.90, raw P90 <= 1.50x, and median scale within [0.80x, 1.25x].

Kendall's tau-b compares the ordering of every pair of cases. 1 means identical ordering, 0 means no consistent ranking association, and -1 means completely reversed ordering.
Spearman's rho correlates the ranks of the two score sets. It also ranges from -1 to 1 and is more sensitive than tau-b to how far individual cases move in the ranking.
The raw P90 symmetric factor is the empirical 90th percentile of exp(abs(log(E_SJ / E_origin))). 1.0x is ideal; 1.5x places that percentile between 1 / 1.5 and 1.5 times the reference value.
The scale-adjusted P90 symmetric factor applies the same calculation after removing the median log ratio. Comparing it with raw P90 separates a mostly fixed scale bias from workload-dependent shape error.

Validation results#
Estimator mode	Comparable cases	Kendall tau-b (95% bootstrap interval)	Spearman rho	Log-Pearson r	Raw P90 factor	Scale-adjusted P90	Median scale E_SJ/E_origin
Lemaire	288	1.00 [1.00, 1.00]	1.00	1.00	1.00x	1.00x	1.00x
SpikeSim dense	216	1.00 [1.00, 1.00]	1.00	1.00	1.00x	1.00x	1.00x
NeuroMC	786	1.00 [1.00, 1.00]	1.00	1.00	1.00x	1.00x	1.00x

Each NeuroMC phase contains 262 fragments. Raw P90 is 1.000x for FE, 1.001x for BE, and 1.000x for WE; all three phase tau-b and median-scale values round to 1.000, and both phase-level and aggregate results pass the gates. All 288 Lemaire cases also pass. SpikeSim's 216 cases match because the dense runtime directly implements the author formula.

Limitations:

The NeuroMC implementation and reference share the same author model. This is a conformance check, not independent validation.
All references are analytical-model outputs, not hardware measurements.
Coverage remains incomplete: published equations reconstruct Lemaire because no author code is public; NeuroMC BN and optimizer formulas, Simple Energy, and SpikeSim event have no independent end-to-end external estimator.

Cross-Validation on Real Networks#

The cross-validation runs VGG-11/13/16/19 and SEW-ResNet-18/34/50 at image sizes 32, 40, 48, and 56, for 28 network cases. VGG uses the non-BN variants; SEW ResNet uses identity normalization. The script first runs each full network, then extracts the inputs of executed Conv2d stages and evaluates the same Conv2d-to-IF stages under all five energy regimes. Results cover only the common convolution-neuron scope, not full-model energy.

Spikformer is excluded because its attention and MLP primarily use Conv1d, while SpikeSim supports only Conv2d; its patch embedding alone does not represent the full network.

Correlation matrices for five energy models on VGG and SEW ResNet — Simple Energy and Lemaire have the closest ranking (Kendall tau-b `0.94`). NeuroMC has tau-b `0.74` with SpikeSim dense and `0.63` with SpikeSim event. The differences reflect memory, mapping, and activity assumptions; they do not identify one model as more accurate.#

For cross-model comparisons, tau-b at or above 0.90 usually indicates highly consistent rankings, while 0.70 to 0.90 indicates strong correlation. These are interpretive ranges, not correctness gates; high correlation does not imply close absolute energy values.

The figure also reports Spearman rho and log-Pearson r. Per-network results for all five regimes are available in the cross-validation CSV.

Run the benchmark manually with:

uv run python benchmark/energy_model_validation.py \
    --spikesim-root /path/to/SpikeSim \
    --neuromc-root /path/to/NeuroMC

Case inputs, paired scores, metrics, and version information are available in the case-level CSV. The benchmark depends on pinned external repositories and does not run in CI.

Summary#

op_counter records the executed work for a given input. Use basic counters for operations and traffic, and energy estimators for relative comparisons within their stated scope. Do not compare absolute values across estimators.
